SAME Deutz-Fahr Hydraulic Inversor 110-130 Workshop Service Repair Manual
This workshop repair manual provides technical information for servicing and repairing the hydraulic inversor system used with SAME Deutz-Fahr 110-130 series applications. The manual is presented as a professional workshop reference from SAME DEUTZ-FAHR Italia S.p.A., with information organized into dedicated technical sections.
The manual begins with General Information, including important safety rules and precautions for tractor operation and maintenance. The sample covers safe starting and operation procedures, stopping procedures, maintenance practices, handling of hydraulic systems, electrical systems, tyres and wheels, emergency preparation, protective equipment, and precautions when working around moving parts and pressurized fluids.
A dedicated Description of Operation section provides the basis for understanding how the hydraulic inversor system functions. This is useful when diagnosing operational problems before beginning component removal or repair work.
The Removal-Refitting and Overhaul section is intended as a workshop reference for disassembly, component inspection, refitting and overhaul work. It can assist technicians in following an organized approach when servicing hydraulic inversor components.
The manual also includes a Troubleshooting section for locating possible faults and identifying areas requiring inspection. In addition, the Electrical System and Electronic Components section provides technical information relating to the electrical and electronic elements associated with the system.
Manual Specifications
| Specification | Details |
|---|---|
| Manual Type | Workshop Service & Repair Manual |
| Product | Hydraulic Inversor |
| Model Range | SAME Deutz-Fahr 110-130 |
| Manufacturer | SAME DEUTZ-FAHR Italia S.p.A. |
| Manual Language | English / Multilingual reference material |
| Number of Pages | 146 Pages |
| File Size | Approximately 5 MB |
| Format | Digital PDF |
| Manual Sections | 5 Main Sections |
| Technical Coverage | Operation, Removal, Refitting, Overhaul, Troubleshooting, Electrical & Electronic Components |
| Suitable For | Workshop technicians, mechanics and qualified repair personnel |
Manual Contents
- General information and safety rules
- Hydraulic inversor description of operation
- Removal and refitting procedures
- Component overhaul information
- Troubleshooting and fault diagnosis
- Electrical system information
- Electronic components
- Maintenance and workshop safety information
- Hydraulic system precautions
- Technical safety and repair procedures
The sample’s section index specifically identifies five main sections: General Information, Description of Operation, Removal-Refitting and Overhaul, Troubleshooting, and Electrical System and Electronic Components. :contentReference[oaicite:1]{index=1}
Safety guidance in the manual emphasizes following recommended maintenance procedures, keeping clear of moving parts, using appropriate protective clothing, handling pressurized fluids carefully, and preventing accidental tractor movement during service work. :contentReference[oaicite:2]{index=2}
This manual is a useful reference for professional technicians, agricultural machinery mechanics, repair workshops and owners carrying out qualified maintenance and repair work on compatible SAME Deutz-Fahr hydraulic inversor systems.
