Description
Manual Specifications
| Manufacturer | Hitachi |
|---|---|
| Model | ZAXIS 450, 450LC, 450H, 450LCH, 460LCH, 480MT and 480MTH |
| Equipment Type | Hydraulic Excavator |
| Manual Type | Parts Catalog |
| Serial Number | 010001 onward |
| Publication Number | P16J-1-3 |
| Pages | 796 pages |
| Download Size | 30 MB |
| Format | Searchable and printable PDF |
| Language | Multilingual (including English and Japanese) |
| Compatibility | Windows, macOS, Linux, Android and iOS |
| Delivery | Instant digital download |
Hitachi ZAXIS 450, 450LC, 450H, 450LCH, 460LCH, 480MT & 480MTH Hydraulic Excavator Parts Catalog PDF – P16J-1-3
This Hitachi parts catalog, publication P16J-1-3, provides illustrated component diagrams, part names, part numbers and applicable serial number references for the ZAXIS 450, 450LC, 450H, 450LCH, 460LCH, 480MT and 480MTH hydraulic excavators, starting from serial number 010001. The catalog includes a numerical parts index and guidance on parts interchangeability.
For excavator owners, equipment maintenance technicians, parts departments, repair workshops and fleet operators identifying replacement components and ordering parts.
What’s Included
- Illustrated parts breakdowns and corresponding parts lists
- Part numbers, names, quantities and service codes
- Machine serial number applicability and replaceable-part information
- Numerical parts index and multilingual catalog instructions
Systems and Components Covered
- Upperstructure, frame, engine mounting, fuel piping and swing devices
- Control levers, pilot piping, electrical parts and cab assemblies
- Undercarriage, track frames, rollers, travel devices and track links
- Backhoe attachments, boom, arm, bucket and front piping
- Automatic lubrication, loader attachments and breaker-related piping
Buy With Confidence
- Detailed technical information for accurate parts identification, maintenance, troubleshooting, or repair
- Searchable PDF for quickly locating required information
- Printable pages for convenient workshop use
- Instant digital delivery with no printed book or shipping delay
Important Notice
Please verify that ZAXIS 450, 450LC, 450H, 450LCH, 460LCH, 480MT and 480MTH and any listed serial number, publication number, or machine specification match your equipment before purchasing. Check the sample PDF when available to confirm that the manual is suitable for your equipment.
Product images are for illustration purposes only and may differ from the actual machine covered by the manual. This product is a digital PDF manual. No printed book will be shipped.
