Description
Manual Specifications
| Manufacturer | Hitachi |
|---|---|
| Model | ZAXIS 330-3, 330LC-3, 350LC-3, 350LCN-3, 350H-3, 350LCH-3, 350K-3 and 350LCK-3 |
| Equipment Type | Hydraulic Excavator |
| Manual Type | Equipment Components Parts Catalog |
| Serial Number | 050001 onward |
| Publication Number | P1V7-E1-1 |
| Pages | 106 pages |
| Download Size | 5 MB |
| Format | Searchable and printable PDF |
| Language | Multilingual (including English and Japanese) |
| Compatibility | Windows, macOS, Linux, Android and iOS |
| Delivery | Instant digital download |
Hitachi ZAXIS 330-3, 330LC-3, 350LC-3, 350LCN-3, 350H-3, 350LCH-3, 350K-3 & 350LCK-3 Hydraulic Excavator Equipment Components Parts Catalog PDF – P1V7-E1-1
This Hitachi ZAXIS 330-3 series Equipment Components Parts Catalog, publication P1V7-E1-1, provides illustrated parts identification for precision components used in the listed hydraulic excavators. The catalog identifies applicable machines from serial number 050001 onward.
Suitable for equipment technicians, parts specialists, maintenance workshops and owners who need to identify component parts and replacement part numbers.
What’s Included
- Illustrated equipment-component parts diagrams and corresponding parts listings
- Part numbers, part names, quantities and replacement-part references
- Guidance for interpreting service codes and parts interchangeability
- Parts index and equipment component contents
Systems and Components Covered
- Hydraulic pump device, pump units, regulator and gear pump
- Swing device, swing motor and swing transmission
- Travel device, travel motor and brake valve
- Control, pilot, solenoid, lock and shuttle valves
- Center joint and boom, arm and bucket cylinders
Buy With Confidence
- Detailed technical information for accurate parts identification, maintenance, troubleshooting, or repair
- Searchable PDF for quickly locating required information
- Printable pages for convenient workshop use
- Instant digital delivery with no printed book or shipping delay
Important Notice
Please verify that ZAXIS 330-3, 330LC-3, 350LC-3, 350LCN-3, 350H-3, 350LCH-3, 350K-3 and 350LCK-3 and any listed serial number, publication number, or machine specification match your equipment before purchasing. Check the sample PDF when available to confirm that the manual is suitable for your equipment.
Product images are for illustration purposes only and may differ from the actual machine covered by the manual. This product is a digital PDF manual. No printed book will be shipped.
