Description
Manual Specifications
| Manufacturer | Hitachi |
|---|---|
| Model | EX120-5, EX120SS-5, EX120-5HG, EX120-5LV, EX120-5X, EX120-5E, EX120-5Z, EX130H-5, EX130K-5 |
| Equipment Type | Hydraulic Excavator |
| Manual Type | Equipment Components Parts Catalog |
| Serial Number | 001001 & Up |
| Publication Number | P1E4-E1-4 |
| Pages | 275 pages |
| Download Size | 17 MB |
| Format | Searchable and printable PDF |
| Language | Japanese (with English component labels and parts table headings) |
| Compatibility | Windows, macOS, Linux, Android and iOS |
| Delivery | Instant digital download |
Hitachi EX120-5 Series, EX130H-5 & EX130K-5 Excavator Equipment Components Parts Catalog PDF – P1E4-E1-4 (Serial No. 001001 & Up, Japanese Edition)
This Hitachi EX120-5 Series, EX130H-5 and EX130K-5 Equipment Components Parts Catalog, publication P1E4-E1-4, is a Japanese domestic-edition parts catalog for applicable machines from serial number 001001. It contains illustrated exploded views and accompanying component parts tables, including part numbers, names, quantities, applicable serial numbers and replacement-part references. The catalog’s instructions are primarily in Japanese, with English labels in parts tables and component headings.
Intended for owners, equipment technicians, parts specialists and repair workshops identifying and ordering hydraulic excavator equipment components. Japanese-language reading ability is recommended.
What’s Included
- Illustrated exploded-view equipment-component diagrams and matching parts tables
- Part numbers, quantities, applicability information and replacement-part references
- Japanese catalog instructions with English parts headings and component names
- Contents and parts index for identifying components
- Serial-number and model-variant applicability notes
Systems and Components Covered
- Hydraulic pump devices, pump units, regulators and pump gears
- Swing and travel oil motors, rotary groups, shafts and brake valves
- Main control valves, pilot valves, relief valves and solenoid valves
- Holding, lock, shuttle, rotary and hose-rupture valves
- Boom, arm, bucket, clamshell, offset and blade hydraulic cylinders
Buy With Confidence
- Detailed technical information for accurate parts identification, maintenance, troubleshooting, or repair
- Searchable PDF for quickly locating required information
- Printable pages for convenient workshop use
- Instant digital delivery with no printed book or shipping delay
Important Notice
Please verify that EX120-5, EX120SS-5, EX120-5HG, EX120-5LV, EX120-5X, EX120-5E, EX120-5Z, EX130H-5, EX130K-5 and any listed serial number, publication number, or machine specification match your equipment before purchasing. Check the sample PDF when available to confirm that the manual is suitable for your equipment.
Product images are for illustration purposes only and may differ from the actual machine covered by the manual. This product is a digital PDF manual. No printed book will be shipped.
