Description
Manual Specifications
| Manufacturer | Hitachi |
|---|---|
| Model | EX120-2 |
| Equipment Type | Hydraulic Excavator |
| Manual Type | Parts Catalog |
| Publication Number | P12N-1-7 |
| Pages | 465 pages |
| Download Size | 32 MB |
| Format | Searchable and printable PDF |
| Language | English and Japanese |
| Compatibility | Windows, macOS, Linux, Android and iOS |
| Delivery | Instant digital download |
Hitachi EX120-2 Hydraulic Excavator Parts Catalog PDF – P12N-1-7
This Hitachi EX120-2 Hydraulic Excavator Parts Catalog, publication P12N-1-7, provides exploded-view component illustrations and matching parts lists for identifying replacement parts. The catalog includes a foreword explaining part-number identification, quantities, service codes, serial-number applicability and interchangeable replacement parts.
Intended for Hitachi EX120-2 excavator owners, parts specialists, service technicians and repair workshops identifying and ordering replacement parts.
What’s Included
- Illustrated exploded-view component diagrams with corresponding parts lists
- Part numbers, part names, quantities and serial-number applicability
- Parts ordering instructions, service-code explanations and interchangeability notes
- Contents and parts index for locating components
- Standard and optional equipment parts references
Systems and Components Covered
- Upperstructure frame, counterweight, engine, radiator, fuel system and hydraulic piping
- Pump device, swing device, pilot piping and controls
- Cab, electrical parts, covers, seats and operator equipment
- Undercarriage track frame, swing bearing, travel device, rollers and track links
- Boom, arm, bucket, front-end attachments and piping
- Optional attachments, rubber crawler parts, tools and spare parts
Buy With Confidence
- Detailed technical information for accurate parts identification, maintenance, troubleshooting, or repair
- Searchable PDF for quickly locating required information
- Printable pages for convenient workshop use
- Instant digital delivery with no printed book or shipping delay
Important Notice
Please verify that EX120-2 and any listed serial number, publication number, or machine specification match your equipment before purchasing. Check the sample PDF when available to confirm that the manual is suitable for your equipment.
Product images are for illustration purposes only and may differ from the actual machine covered by the manual. This product is a digital PDF manual. No printed book will be shipped.
