Eaton Fuller HD FR/FRO Transmissions TRSM2400 Service Manual
The Eaton Fuller TRSM2400 Service Manual is designed to provide the service and repair information required for the Eaton Fuller HD FR/FRO transmission family covered by the publication. The manual is organized to help technicians locate the required procedure quickly, with separate sections for work that can be performed while the transmission remains installed in the vehicle and procedures performed after transmission removal.
Manual Specifications
| Manual Type | Service & Repair Manual |
| Manufacturer | Eaton Fuller |
| Transmission Family | HD FR/FRO Transmissions |
| Manual Number | TRSM2400 |
| Publication Date | April 2013 |
| Document Reference | FR-11210B / FR-12210B / FR-13210B / FR-14210B / FR-15210B / FR-9210B and related FRF/FRO/FROF models |
| Total Pages | 196 Pages |
| File Format | |
| Download Size | 16 MB |
| Service Coverage | In-Vehicle Service & Transmission Overhaul |
Comprehensive Service & Repair Information
This manual covers both In-Vehicle Service Procedures and Transmission Overhaul Procedures β Bench Service. The procedures include removal, installation, disassembly, inspection and assembly operations for major transmission components and assemblies.
The contents include procedures for the Roadranger valve, gear shift lever and remote shift control, shift bar housing, neutral and reverse switches, speedometer oil seals, auxiliary section, integral oil cooler, air module and other transmission components.
Transmission Overhaul Procedures
The overhaul section provides extensive bench-service procedures covering the major transmission assemblies. Topics include input shaft assembly, auxiliary section, range yoke, output shaft, synchronizer assembly, countershaft assemblies, mainshaft assembly, reverse idler gears, bearings, clutch housing, oil pump, oil seals and final auxiliary-section installation.
Inspection & Assembly Guidance
The manual provides inspection precautions for bearings, gears, clutch release parts, shift bar housing components, sliding clutches, splines, synchronizers, washers, O-rings and other transmission components. It also explains assembly precautions intended to help maintain cleanliness, correct lubrication and proper component installation.
For example, the manual emphasizes checking bearings for pitting, discoloration, spalling and excessive clearance before reuse. It also provides guidance for checking gears, synchronizers, splines and other components for abnormal wear or damage.
Specifications & Technical Information
Technical sections include lubrication specifications, tool specifications, torque specifications, power flow diagrams, air-system troubleshooting, general troubleshooting and timing procedures. The manual also contains transmission model designation information to assist with identifying the correct transmission configuration.
Model Identification
The model-designation section explains the information found on the Eaton Fuller transmission serial tag. The manual shows how the model number identifies features such as the Eaton Fuller model designation prefix, nominal torque capacity, auxiliary gearing, forward speeds and ratio set.
The manual covers model prefixes including FR, FRF, FRO and FROF. The supplied sample also illustrates the transmission identification tag and explains the importance of recording the model and serial numbers when requesting service assistance or replacement parts.
Professional Workshop Reference
With its combination of troubleshooting information, service procedures, overhaul instructions, inspection guidance and technical specifications, the TRSM2400 manual is a useful reference for professional transmission repair and rebuilding work.
Important: Always verify the transmission model, serial number and applicable specifications before beginning service work. Follow the safety warnings and procedures provided in the manual.
- General transmission information
- Purpose and scope of the service manual
- Serial tag information and model nomenclature
- Lubrication specifications
- Oil leak inspection process
- Transmission operation
- Tool specifications
- Torque specifications
- Power flow diagrams
- Air system troubleshooting
- General troubleshooting chart
- Air system overview
- Timing procedures
- In-vehicle service procedures
- Roadranger valve service
- Gear shift lever and remote shift control procedures
- Neutral and reverse switch testing and replacement
- Shift bar housing removal and installation
- Auxiliary section service
- Integral oil cooler service
- Air module removal and installation
- Transmission overhaul and bench-service procedures
- Mainshaft and countershaft procedures
- Input shaft and main drive gear procedures
- Synchronizer assembly procedures
- Range yoke and range cylinder procedures
- Reverse idler gear procedures
- Oil pump and oil seal procedures
- Auxiliary section assembly and installation
- Tapered bearing shim procedure
