Eaton Fuller AutoSelect & AutoShift Service Manual
The Eaton Fuller AutoSelect & AutoShift Automated Transmissions Service Manual TRSM-0050 is a detailed service reference designed for technicians and mechanics working with Eaton Fuller automated transmission systems. The manual explains the service procedures for the transmission automation components and provides organized instructions to help locate and perform specific repair procedures.
The manual begins with important warnings, cautions, identification information, model designations, lubrication requirements, and preventive maintenance procedures. It explains how to identify the transmission using its model and serial number and provides information about AutoSelect and AutoShift nomenclature.
Manual Specifications
| Product Name | Eaton Fuller AutoSelect & AutoShift Automated Transmissions Service Manual TRSM-0050 |
|---|---|
| Manual Type | Service Manual |
| Manual Number | TRSM-0050 |
| Brand | Eaton Fuller / Roadranger |
| Transmission Systems | AutoSelect & AutoShift Automated Transmissions |
| Publication | May 2004 |
| Language | English |
| Format | |
| Total Pages | 128 |
| File Size | 6 MB |
| Delivery | Digital Download |
| Content | Service, Repair, Maintenance & Component Procedures |
Comprehensive Service Procedures
The service section covers a wide range of automation components. Each component is presented with an overview followed by dedicated removal and installation procedures, making the manual useful when carrying out component-level service and repairs.
Coverage includes the Reverse Ball Switch, Rail Select Sensor, Gear Select Sensor, Input/Main Shaft Speed Sensors, Output Shaft Speed Sensor, Range Valve, Splitter Valve, Air Filter/Regulator, Inertia Brake Solenoid, Inertia Brake, Power Module, Electric Shifter, Transmission ECU, Transmission Harness, Shift Lever, Power Relay, System Manager, Tower Harness, and Gear Display.
Maintenance & Lubrication Information
The manual also contains important preventive maintenance information. It covers recommended lubricants, lubrication intervals, oil-level inspection, transmission inspections, air-leak checks, lubricant-leak checks, and inspection of loose or missing bolts.
The manual specifically discusses on-highway and off-highway maintenance considerations and provides lubricant-change guidance for AutoSelect and AutoShift transmissions. The lubrication section references Eaton-approved lubricants meeting the PS-164 / E-500 performance requirements.
Clear Technical Organization
The table of contents organizes the manual into an introduction and detailed service procedures. This makes it easy to locate a specific component and move directly to its overview, removal procedure, or installation procedure.
Whether used for workshop reference, maintenance planning, troubleshooting support, or component replacement, this manual provides a structured technical reference for Eaton Fuller AutoSelect and AutoShift automated transmission systems.
Manual Highlights
- Detailed Eaton Fuller AutoSelect and AutoShift service information
- Component-specific removal and installation procedures
- Transmission automation component coverage
- Preventive maintenance information
- Lubrication and lubricant-change information
- Safety warnings and service cautions
- Transmission identification and model designation information
- Technical diagrams and illustrations
- Organized table of contents for quick reference
Important Coverage Note
This manual is focused on transmission automation components. The manual itself states that service information for the mechanical portion of the transmission system should be referenced in the applicable model-specific transmission service manual.
