Description
Eaton Fuller AutoSelect & AutoShift Service Manual TRSM-0050
The Eaton Fuller AutoSelect & AutoShift Automated Transmissions Service Manual TRSM-0050 is a detailed service reference designed for servicing and repairing the automation components of Eaton Fuller automated transmissions. The manual explains how to locate and follow individual service procedures using its structured table of contents.
The manual covers important introductory information including transmission identification, model designations, lubrication requirements, maintenance intervals, preventive maintenance inspections, warnings, and cautions. The model nomenclature section explains AutoSelect and AutoShift identification formats, including gear ratio, forward speeds, design level, torque capacity, and related designations.
Manual Specifications
| Product Name | Eaton Fuller AutoSelect & AutoShift Automated Transmissions Service Manual |
|---|
| Manual Number | TRSM-0050 |
|---|
| Publication Date | May 2004 |
|---|
| Manual Type | Service Manual |
|---|
| Language | English |
|---|
| Format | PDF |
|---|
| Total Pages | 128 |
|---|
| Download Size | 5 MB |
|---|
| Transmission Type | Automated Transmissions |
|---|
| Systems Covered | AutoSelect & AutoShift |
|---|
| Brand | Eaton Fuller / Roadranger |
|---|
| Compatibility | PDF-compatible devices |
|---|
| Delivery | Instant Digital Download |
|---|
Comprehensive Service Procedures
The main service section provides organized removal and installation procedures for a wide range of transmission automation components. Each component is presented with an overview followed by dedicated removal and installation procedures, making the manual useful when carrying out component-level service work.
- Reverse Ball Switch
- Rail Select Sensor
- Gear Select Sensor
- Input/Main Shaft Speed Sensors
- Output Shaft Speed Sensor
- Range Valve
- Splitter Valve
- Air Filter/Regulator
- Inertia Brake Solenoid
- Inertia Brake
- Power Module
- Electric Shifter
- Transmission ECU
- Transmission Harness
- Shift Lever
- Power Relay
- System Manager
- Tower Harness
- Gear Display
Maintenance & Lubrication Information
The manual also provides preventive maintenance guidance covering transmission inspections, lubricant changes, air leaks, loose or missing bolts, and lubricant leaks. The sample pages explain recommended Eaton-approved lubricants meeting the PS-164/E-500 requirements and provide maintenance information for both on-highway and off-highway applications.
The lubrication section also explains how to check the transmission oil level and illustrates the difference between a proper and improper lubricant level. This information can help technicians follow the recommended maintenance practices for Eaton Fuller automated transmissions.
Why This Manual Is Useful
- Detailed component-level service procedures
- Removal and installation instructions
- Transmission automation component coverage
- Sensor, valve, ECU and harness service information
- Preventive maintenance and lubrication guidance
- Safety warnings, cautions and service notes
- Clear organization through a detailed table of contents
The sample’s table of contents shows service procedures extending from the Reverse Ball Switch through the Gear Display, with dedicated overview, removal, and installation sections. :contentReference[oaicite:0]{index=0} The manual states that its service procedures are specifically intended for the transmission automation components, while the mechanical portion of the transmission should be serviced using the applicable model-specific transmission service manual. :contentReference[oaicite:1]{index=1}
Manual reference: TRSM-0050, May 2004. The supplied manual identifies Eaton Fuller Automated Transmissions and AutoSelect/AutoShift systems on its cover. :contentReference[oaicite:2]{index=2}
