Description
Official CLAAS JAGUAR Hydraulic Technical System Manual
This factory workshop manual covers the complete hydraulic systems used on the CLAAS JAGUAR 900, 830 PROFISTAR, and SPEEDSTAR forage harvesters equipped with the Electro-Hydraulic Ground Drive (EFA). It provides detailed hydraulic circuit diagrams, system operation, hydraulic component identification, pressure control information, valve functions, and troubleshooting procedures.
The manual is intended for professional service technicians, agricultural equipment repair shops, and experienced owners who require accurate OEM hydraulic information for inspection, maintenance, diagnostics, and repair.
| Product | Factory Technical Hydraulic System Manual |
|---|---|
| Manufacturer | CLAAS |
| Machine Models | JAGUAR 900, JAGUAR 830, JAGUAR PROFISTAR, JAGUAR SPEEDSTAR |
| System Covered | Technical Hydraulic System |
| Ground Drive | Electro-Hydraulic Ground Drive (EFA) |
| Document Format | |
| Language | English |
| Total Pages | 168 Pages |
| Download Size | 4 MB |
| Compatibility | Windows, macOS, Linux, Android & iOS |
| Delivery | Instant Digital Download , Life Time Access |
| Printable | Yes |
| Searchable PDF | Yes |
Manual Covers
- Complete overall hydraulic system
- Hydraulic circuit diagrams
- Steering hydraulic system
- Working hydraulic system
- Low-pressure hydraulic system
- Ground drive hydraulic system
- Electro-hydraulic ground drive (EFA)
- Hydraulic valve functions
- Valve insert identification
- Hydraulic pumps and motors
- Hydraulic cylinders
- Pressure accumulators
- Pressure relief valves
- Flow control valves
- Hydraulic oil cooler
- Hydraulic oil tank
- Return filters
- Ground drive pumps and motors
- Steering Orbitrol system
- Hydraulic sensors and switches
- Solenoid valve identification
- Component location references
- Compressed-air system
- Technical hydraulic specifications
- OEM hydraulic troubleshooting information
Factory Hydraulic Diagrams Included
The manual contains professionally detailed hydraulic schematic diagrams showing complete oil flow circuits, hydraulic symbols, valve arrangements, pumps, motors, hydraulic cylinders, accumulators, pressure regulating valves, shuttle valves, steering systems, and electro-hydraulic controls. These diagrams greatly simplify troubleshooting and repair of complex hydraulic faults.
Ideal For
- CLAAS dealership technicians
- Agricultural machinery workshops
- Farm maintenance departments
- Independent repair professionals
- Hydraulic specialists
- Owners performing advanced repairs
This genuine factory service information allows accurate diagnostics while reducing repair time and avoiding unnecessary replacement of hydraulic components.
