Description
Bendix Gen 4 & Gen 5 ABS Service Data Manual (SD-13-4746)
The official Bendix Gen 4β’ and Gen 5β’ ABS Service Data Manual provides complete factory service information for diagnosing, servicing, and maintaining Bendix Anti-lock Braking Systems (ABS) and Automatic Traction Control (ATC) systems used on commercial vehicles.
This manual covers both cab-mounted and frame-mounted electronic control units (ECUs) installed on trucks, tractors, buses, motor coaches, and recreational vehicles. It includes detailed explanations of system operation, component functions, diagnostic procedures, troubleshooting methods, and repair instructions used by professional technicians.
Step-by-step procedures explain ABS operation, pressure modulator valve testing, wheel speed sensor diagnosis, ECU configuration, diagnostic trouble codes, relay valve performance testing, ATC system operation, and ECU pin identification for both cab-mounted and frame-mounted controllers.
| Product | Bendix Gen 4 & Gen 5 ABS Service Data Manual |
|---|
| Document Number | SD-13-4746 |
|---|
| Manufacturer | Bendix |
|---|
| Compatible Systems | Gen 4β’ & Gen 5β’ ABS / ATC |
|---|
| Vehicle Applications | Trucks, Tractors, Buses, Motor Coaches & RVs |
|---|
| Language | English |
|---|
| Format | PDF |
|---|
| Pages | 48 |
|---|
| Download Size | 4 MB |
|---|
| Delivery | Instant Download , Life Time Access |
|---|
Manual Covers
- ABS System Operation
- Automatic Traction Control (ATC)
- ABS Components Overview
- Electronic Control Units (ECU)
- Pressure Modulator Valves
- ABS Indicator Lamp Operation
- System Configurations
- Diagnostic Trouble Codes (DTC)
- Configuration Code Reading
- ServiceRanger Software Information
- Wheel Speed Sensor Testing
- Sensor Memory Diagnostics
- Wheel End Sensor Repair
- Pressure Modulator Valve Troubleshooting
- ATC Valve Service Procedures
- Relay Valve Performance Testing
- Cab Mount ECU Pin Identification
- Frame Mount ECU Pin Identification
Package Includes
- Official Bendix Factory Service Data Manual
- Searchable PDF Format
- Instant Digital Download
- Compatible with Windows, Mac, Tablets and Mobile Devices
- High Quality Printable Manual
This factory manual is an essential reference for technicians performing maintenance, diagnostics, troubleshooting, repairs, and system configuration on Bendix Gen 4β’ and Gen 5β’ ABS braking systems.
