Deutz-Fahr Agrotron K 90 100 110 120 Front Axle Repair Manual

Description

Deutz-Fahr Agrotron K 90-100-110-120 Front Axle Repair Manual

This professional Front Axle Repair Manual covers the Carraro Mod. 20.19 front axle assembly identified by references CA641391-92-93-94 and publication P/N CA357358. The manual is structured as a workshop reference for inspection, maintenance, repair, disassembly and reassembly of the front axle.

The manual begins with important general information and safety instructions, including correct manual use, safety symbols, general precautions, product identification and technical information. It also explains the conventions and measurement systems used throughout the repair procedures.

Manual Specifications

Detailed Repair and Maintenance Information

The manual provides practical information for servicing the axle, including oil changes and checks, lubrication and greasing, adhesives and sealants, tightening torques, adjustments and measurements. These sections help technicians follow the required procedures during routine maintenance and complete overhaul work.

Disassembly & Assembly Procedures

A major section of the manual is dedicated to detailed disassembly and assembly operations. The contents include procedures for the sensor group, steering cylinder, epicyclic reduction gear, wheel hub, flange, differential supports, differential assemblies, pinion and axle beam. The manual also covers toe-in and steering-angle adjustment and testing after assembly.

Troubleshooting & Diagnosis

The troubleshooting section provides information for examining faults and diagnosing problems associated with the axle. This makes the manual useful when investigating abnormal operation, component wear or other front axle-related problems.

Special Tools & Service Information

The manual also includes a dedicated section for special tools and a service operation time schedule, providing additional workshop information for professional repair work.

The repair instructions emphasize proper cleaning, inspection of bearings, gears, shafts, seals and other components, correct use of replacement parts, suitable extractors and appropriate assembly methods. The manual also provides specific recommendations for shaft seals, O-rings, adjusting shims, bearings, elastic pins and sealing materials.

Important: The source manual states that the axle is assumed to have already been removed from the vehicle when carrying out the described repair operations. Vehicle-specific axle removal procedures should therefore be referred to in the relevant vehicle manufacturer’s manual.
