FAULT CODE 352

Sensor Supply 1 Circuit - Voltage Below Normal, or Shorted to Low Source

Overview


CODE

REASON

EFFECT

Fault Code: 352

Sensor Supply 1 Circuit - Voltage Below Normal, or Shorted to Low Source. Low voltage

Loss of some sensor

PID:

detected at sensor supply 1 circuit.

functionality.

SPN: 3509



FMI: 4



LAMP: Amber



SRT:



BwkXzrLtXrL7AAAAAElFTkSuQmCC

Sensor Supply 1 Circuit - Industrial Engines


Z

Sensor Supply 1 Circuit - Marine Engines


Z

Sensor Supply 1 Circuit - Power Generation Engin


Circuit Description

Sensor supply 1 from the engine control module (ECM) provides 5-VDC supply for the engine oil rifle pressure 1 sensor on the engine harness. This 5-VDC supply also powers two optional original equipment manufacturer (OEM) devices. The two devices are, remote accelerator pedal or lever position sensor, and OEM pressure sensor.


Component Location


The sensor supply 1 is located in the ECM. The supply voltage is spliced off in the engine and OEM harness to each sensor it supports.


Shop Talk


Low voltage on the 5-VDC supply wire can be caused by a short to ground in a supply wire, a short circuit between a SUPPLY wire and a RETURN wire, a damaged sensor, or a damaged battery 1 voltage.


Refer to Troubleshooting Fault Code t05-352.


Last Modified: 15-Jan-2013

Copyright © 2000-2010 Cummins Inc. All rights reserved.
