CUMMINS FAULT CODE 224

By /

ADVERTICEMENT

cummins insite keygen
mk:@MSITStore:C:\Users\HP\Desktop\Backup\Insite\Cummins%20FIS\F


FAULT CODE 224

Engine Oil Burn Valve Solenoid Driver Circuit - Voltage Above Normal or Shorted to High Source

Overview


CODE

REASON

EFFECT

Fault Code: 224

Engine Oil Burn Valve Solenoid Driver Circuit - Voltage Above Normal or Shorted to

Engine control module (ECM) turns

PID:

High Source. High voltage has been detected at the Centinelâ„¢ burn valve solenoid

off the burn valve solenoid driver

SPN: 1265

driver pin in the engine harness 50-pin connector or resistance of the solenoid is

supply voltage and the system is

FMI: 3

above specifications.

disabled.

LAMP: Amber



SRT:



Engine Oil Burn Valve Solenoid Driver Circuit


Circuit Description


The engine oil burn valve solenoid driver controls the flow of oil in the oil control valve during the burn cycle.


Component Location


Refer to the original equipment manufacturer (OEM) service manual for the engine oil burn valve solenoid driver location.


Shop Talk

This fault code can be caused by the following:


  • A damaged Centinelâ„¢ burn valve

  • An open circuit in the output device driver return wire

  • A pin-to-pin short in the output device driver wire.


Refer to Troubleshooting Fault Code t05-224.


Last Modified: 28-Nov-2012

Copyright © 2000-2010 Cummins Inc. All rights reserved.
