cummins insite keygen
mk:@MSITStore:C:\Users\HP\Desktop\Backup\Insite\Cummins%20FIS\F


FAULT CODE 223

Engine Oil Burn Valve Solenoid Driver Circuit - Voltage Below Normal or Shorted to Low Source

Overview


CODE

REASON

EFFECT

Fault Code: 223

Engine Oil Burn Valve Solenoid Driver Circuit - Voltage Below Normal or Shorted to Low

Engine control module (ECM)

PID:

Source. The Centinel™ burn valve solenoid circuit is shorted. Less than 18.0-VDC

turns off the burn valve solenoid

SPN: 1265

detected at the Centinel™ burn valve solenoid SUPPLY pin of the 50-pin harness

driver supply voltage and the

FMI: 4

connector or resistance of the solenoid has dropped below specifications.

system is disabled.

LAMP: Amber



SRT:



Engine Oil Burn Valve Solenoid Driver Circuit


Circuit Description


The engine oil burn valve solenoid driver controls the flow of oil in the oil control valve during the burn cycle.


Component Location


Refer to the OEM service manual for the engine oil burn valve solenoid driver location.


Shop Talk

This fault can be caused by the following:


  • A damaged Centinel™ burn valve

  • A short circuit to ground on the output device driver wire

  • A short circuit from pin to pin in the output device driver wire.


Refer to Troubleshooting Fault Code t05-223.


Last Modified: 28-Nov-2012

Copyright © 2000-2010 Cummins Inc. All rights reserved.
