CUMMINS FAULT CODE 135

By /

ADVERTICEMENT

cummins insite keygen
mk:@MSITStore:C:\Users\HP\Desktop\Backup\Insite\Cummins%20FIS\F


FAULT CODE 135

Engine Oil Rifle Pressure 1 Sensor Circuit - Voltage Above Normal or Shorted to High Source

Overview


CODE

REASON

EFFECT

Fault Code: 135

Engine Oil Rifle Pressure 1 Sensor Circuit - Voltage Above Normal or Shorted to

None on performance. No engine

PID:

High Source. High signal voltage detected at the engine oil pressure circuit.

protection for oil pressure

SPN: 100



FMI: 3



LAMP: Amber



SRT:



Engine Oil Rifle Pressure 1 Sensor Circuit


Circuit Description


The engine oil rifle pressure 1 sensor is used by the engine control module (ECM) to monitor the lubricating oil pressure. The ECM monitors the voltage on the signal pin and converts this to a pressure value.


Component Location


The intake manifold 1 pressure sensor is located in the air intake. Use the following procedure for a detailed component location view. Refer to Procedure 100-002 in Section E.

Shop Talk


The engine oil rifle pressure 1 sensor shares supply and return wires in the engine harness with other sensors. Opens and shorts in the engine harness can cause multiple fault codes to be active. Before troubleshooting Fault Code 135, check for multiple faults.


Possible causes of this fault code include:


  • Open return circuit in the harness, connectors, or sensor

  • Signal circuit shorted to sensor supply or battery voltage.


Refer to Troubleshooting Fault Code t05-135.


Last Modified: 26-Nov-2012

Copyright © 2000-2010 Cummins Inc. All rights reserved.
