FAULT CODE 266

Engine Fuel Temperature - Data Valid But Above Normal Operating Range - Most Severe Level

Overview


CODE

REASON

EFFECT

Fault Code: 266

Engine Fuel Temperature - Data Valid But Above Normal

Power derate and possible engine shutdown id engine

PID:

Operating Range - Most Severe Level.

protection shutdown feature is enabled.

SPN: 174



FMI: 0



LAMP: Red



SRT:



Engine Fuel Temperature Sensor 1 Circuit - Power Generation

Engines


Engine Fuel Temperature Sensor 1 Circuit - Marine En


Circuit Description


The engine fuel temperature sensor 1 is used by the engine control module (ECM) to monitor engine fuel supply temperature. The ECM monitors the voltage on the engine fuel temperature signal pin and converts this to a temperature value. The engine fuel temperature value is used by the ECM for the engine protection system.

Component Location


The engine fuel temperature sensor 1 is located on the fuel filter housing. Use the following procedure for a detailed component location view. Refer to Procedure 100-002 in Section E.


Shop Talk


All Temperature Sensors


  • The resistance of the sensor varies with the temperature. If the sensor is operating properly, the observed reading will be comparable to the values in the following table.


Temperature (°C)

Temperature (°F)

Resistance (ohms)

0

32

30k to 36k

25

77

9k to 11k

50

122

3k to 4k

75

167

1350 to 1500

100

212

600 to 675

Refer to Troubleshooting Fault Code t05-266.


Last Modified: 29-Nov-2012

Copyright © 2000-2010 Cummins Inc. All rights reserved.
